OEM High Quality Medical X Ray Tube Factory - Medical X-ray Collimator Manual X-ray Collimator SR103 – Sailray

1. Two layers of protection.

2. Traditional knob operation.

3. Interruptible delay lamp.

4. LED lamp.

5. Mixer can choose laser locator.

X-ray leakage: <1mGy/h (120kV, 4mA)
 Distance from X-ray tube ball focus to beam limiter mounting surface: 45mm
Maximum irradiation field: 43cmX43cm (SID=100cm)
Minimum irradiation field: <5cmX5cm (SID=100cm)
LED light field power supply 24VAC/20W or 24VDC/2A
 Visible light field brightness: >140lux (SID=100cm)
Light field consistency: <2%@SID
Inherent filtration: 1mmAl/75kV
 Dimensions: 170mm×152mm×100mm (length×width×height)
Weight: 2.6

Optional:
Special electrical interface
Special tube ball interface
One word line laser locator (type 2)

This x-ray collimator is applicable for  mobile or portable X-ray diagnostic equipment with a tube voltage of 120kV.

1. The warranty period of the factory is 12 months (excluding the bulb) from the date
the customer receives the collimator.
2. Quality problems do not include malfunctions caused by installation, handling, etc.
3. During the warranty period, if the application is not made in writing and approved
by our factory, the machine may not be disassembled, otherwise the consequences
will be borne by itself and no warranty will be given.

Minimum Order Quantity: 1pc

Price: Negotiation

Packaging Details: 100pcs per carton or customized according to the quantity

Delivery Time: 1~2 weeks according to the quantity

Payment Terms: 100% T/T in advance or WESTERN UNION

Supply Ability: 1000pcs/ month
