Medical X-ray Tube XD3A
Medical X-ray Tube XD3A
This tube, RT13A-2.6-100 is designed for general diagnostic x-ray unit and available for a nominal tube voltage with self-rectified circuit.
RT13A-2.6-100 tube has one focus.
The integrated high quality tube with glass design has one super imposed focal spot and a reinforced anode.
The high anode heat storage capacity ensures a wide range of applications for general diagnostic x-ray application. A special designed anode enables an elevated heat dissipation rate which leads to a higher patient throughput and a longer product life. A constant high dose yield during the entire tube life is ensured by the high density tungsten target. Ease of integration into system products is facilitated by extensive technical support.
RT13A-2.6-100 is Portable Diagnostic stationary anode X-ray tube, designed for general diagnostic x-ray unit and available for a nominal tube voltage with self-rectified circuit.
| Nominal Tube Voltage | 105kV |
| Nominal Inverse Voltage | 115kV |
| Nominal Focal Spot | 2.6(IEC60336/1993) |
| Max Anode Heat Content | 30000J |
| Target Angle | 19° |
| Filament Characteristics | 4.5A, 7.0±0.7V |
| Permanent Filtration | Min. 0.8mmAl/50kv(IEC60522/1999) |
| Target Material | Tungsten |
| Tube Current | 50mA |
Elevated anode heat storage capacity and cooling
Constant high dose yield
Excellent lifetime
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: 100pcs per carton or customized according to the quantity
Delivery Time: 1~2 weeks according to the quantity
Payment Terms: 100% T/T in advance or WESTERN UNION
Supply Ability: 1000pcs/ month
